| SKU | O.D x Height (mm) |
|---|---|
| 005.230.2 | Shaft 6, L 300mm, Rotor Ø 40 |
| 005.240.2 | Shaft 6, L 400mm, Rotor Ø 40 |
| 005.250.2 | Shaft 6, L 500mm, Rotor Ø 50 |
| 005.230.8.2 | Shaft 8, L 300mm, Rotor Ø 40 |
| 005.240.8.2 | Shaft 8, L 400mm, Rotor Ø 40 |
| 005.250.8.2 | Shaft 8, L 500mm, Rotor Ø 50 |
| 005.255.2 | Shaft 9.5, L 550mm, Rotor Ø 60 |
| 005.265.2 | Shaft 9.5, L 650mm, Rotor Ø 60 |
| 005.0265.2 | Shaft 9.5, L 650mm (EX), Rotor Ø 60 |
| 005.0275.2 | Shaft 9.5, L 750mm (EX), Rotor Ø 60 |
| 005.255.10.2 | Shaft 10, L 500mm, Rotor Ø 70 |
| 005.0265.10.2 | Shaft 10, L 650mm (EX), Rotor Ø 70 |
| 005.0275.10.2 | Shaft 10, L 750mm (EX), Rotor Ø 70 |
| 005.0265.12.2 | Shaft 12, L 650mm (EX), Rotor Ø 80 |
| 005.0275.12.2 | Shaft 12, L 750mm (EX), Rotor Ø 80 |
| 005.02100.12.2 | Shaft 12, L 1000mm (EX), Rotor Ø 80 |
| 005.0275.16.2 | Shaft 16, L 750mm (EX), Rotor Ø 80 |
| 005.0275.16.1.2 | Shaft 16, L 750mm (EX), Rotor Ø 100 |
| 005.02100.16.2 | Shaft 16, L 1000mm (EX), Rotor Ø 100 |
| 005.02100.16.1.2 | Shaft 16, L 1000mm (EX), Rotor Ø 120 |
If you require bulk quantities, ongoing supply or customer-specific pricing, our team can help.
Speak with us about trade pricing, regular orders and tailored quotes for your laboratory requirements.
| Material | Virgin-grade PTFE with stainless steel core |
| Form | Screw Propeller Shaft Stirrer |
| Scale | -200°C to 260°C |
| Standard | FDA and USP Class VI |
| Features | Fused PTFE rotor; PTFE-encapsulated stainless steel shaft; virtually total chemical resistance; easy to clean; robust; break resistant; autoclavable; EX models with 50 mm exposed stainless steel core |
| Applications | Laboratory and process mixing |
PTFE Shaft Stirrer, Screw Propeller, designed for laboratory and process mixing where chemical resistance, easy cleaning and robust construction are important. The PTFE rotor is fused to a PTFE-encapsulated stainless steel shaft, providing a durable, break-resistant stirring assembly. Virgin grade PTFE conforms to FDA and USP Class VI requirements and offers virtually total chemical resistance. The stirrer operates from -200°C to 260°C (-328°F to 500°F), is autoclavable and has an indefinite shelf life under normal use and storage conditions. Exposed shaft models (EX) provide a 50 mm exposed stainless steel core for a more rigid chuck connection.
