The A&D AD-4212B-301 Precision Weighing Sensor is designed for higher-capacity precision weighing in automated production systems. Its separate sensor and display units support integration into specialised machinery, while its comparator and data-output functions assist with process control and weighing documentation.
Key Features
- Super Hybrid Sensor technology for precision weighing
- Separate sensor and display units for installation flexibility
- Protective mechanism against vertical and transverse overloads
- Adjustable response characteristics to help minimise the influence of drafts and vibration
- Wall or panel mounting option for the display unit
- Support for custom-designed weighing pans
- Comparator contact output with buzzer
- Data memory, clock and calendar functions
- Counting and percentage weighing modes
- GLP/GMP/GCP/ISO-compliant weighing output
- Stainless-steel breeze break and calibration weight included
- Mounting fixtures for securing the sensor unit to a base
Specifications
-
Brand: A&D Weighing
-
Model: AD-4212B-301
-
Product Type: Precision Weighing Sensor
-
Capacity: 310g
-
Readability / Minimum Weighing Value: 0.1mg
-
Weighing Pan: 50 x 50mm
-
Repeatability: 0.2mg
-
Linearity: ±0.3mg
-
Stabilisation Time: Approximately 2.5 seconds under specified conditions
-
Sensor Unit Dimensions: 80(W) x 230(D) x 90(H)mm
-
Display Unit Dimensions: 237(W) x 150(D) x 155(H)mm
-
Connection Cable: Approximately 2m
-
Standard Interface: RS-232C with comparator output
-
Power Supply: AC adaptor
