The A&D EK-12KEP Intrinsically Safe Compact Scale is designed for higher-capacity weighing in approved hazardous environments. With a 12kg capacity and 1g readability, it combines compact construction, a backlit LCD and battery-powered operation for industrial weighing tasks where intrinsically safe equipment is required.
Key Features
- IECEx and ATEX compliance for approved hazardous-area applications
- Compact and lightweight construction
- Backlit LCD with 16mm character height for clear readings
- Automatic power-off function to help conserve battery power
- Comparator function for checking weight against preset limits
- Automatic Counting Accuracy Improvement (ACAI) for improved piece-counting accuracy
- Counting, percentage and specific gravity weighing modes
- Adjustable response characteristics to accommodate drafts and vibration
- Security ring for wire-locking the balance against theft
- Battery-powered operation without a power supply connection through a safety barrier
Specifications
-
Brand: A&D Weighing
-
Model: EK-12KEP
-
Part Number: 06046300
-
Series: EK-EP
-
Capacity: 12kg
-
Readability: 1g
-
Weighing Pan: 133 x 170mm
-
Pan Material: Stainless steel
-
Display: Backlit LCD, 16mm character height
-
Power Supply: Four AA alkaline batteries
-
Battery Life: Approximately 250 hours, depending on operating conditions
-
Certification: IECEx certificate IECEx FMG 15.0006X; refer to the current certificate for applicable conditions of use
